|Specification will be changed for improvement without notice.|
|1)@The machine is pellet machine to polish work piece by piece with chucking
@@by special lens holder. Conventional sticking lens dish can not be used.
@@Conplicate job such as sticking lens on lens dish and peeling off sticked lens
@@is eliminated without being soiled asd pitch and etc. are not used.@Stable
@@polishing can be obtained with preventing pellet flaw caused by stopping
@@spindle on account of sophisticate design.
2)@Work under 150 mm. diameter with lens radius between 20 and 100 mm. is polished.
3)@Functions are controlled by eash spindle.
4)@Upper spindle is moved following the locus of approximate ellipse with
@@warrantable mechanism and tommy-bar can be directed to spherical center on
@@concave or convex surface.
5)@Work pressure is controlled by air and tommy-bar is moved to up and down by
@@foot pedal.@Polishing time is set by timer.@Work is pressurized by pushing
@@start button and released by finishing of polishing.
6)@Abrasive liquid tank with casters is easy to handle.
